Deep Drawing
Deep drawing forms sheet metal into deep, seamless hollow shapes through single- or multi-stage draws, producing strong shells and enclosures without joints or welds.
It suits parts that must be leak-tight and structurally sound, such as cans, cups and housings.
CapabilitySheet Metal & Stamping
DeliveryBuild-to-print, in-house managed
QualityIATF 16949 & ISO 9001
Typical materials
Stainless steelAluminiumCRCA steelBrass
Deep Draw Capabilities
✓Seamless deep-drawn shapes
✓Single- and multi-stage draws
✓Consistent wall thickness
✓High strength without welds
✓Leak-tight shells and cups
✓Repeatable dimensional control
Components Produced with Deep Draw
✓Enclosures and housings
✓Cans, cups and shells
✓Motor cups
✓Filter bodies
✓Deep-formed covers
✓Pressure-tight components
Explore Sheet Metal & Stamping
Part of our Sheet Metal & Stamping capability. Explore the related processes we offer under one accountable partner.
Capacity & specifications
Deep Drawing Capacity
Machine tonnage, material grades and lead times as quoted in the Marcus capability profile.
Machine tonnage
Up to 1000 T
Press tonnage
Processes
Progressive die stamping
Transfer die stamping
Deep draw stamping
Lead times
- 4–6 weeksTooling
- 1 weekFAIR samples
- 4–6 weeksProduction
Materials
Material family
Grades
Aluminium 1000 series
1050106010701100
Aluminium 3000 series
30033105
Aluminium 5000 series
505250835754
Aluminium 6000 series
6016606160636111
Steel
SSMS CRHRGIC45C60Spring steel
Copper alloys
CopperBeryllium phosphorBrassBronze
Secondary operations
Powder coating and paintingBead / shot blastingAnodisingPlatingWet paintingHeat treatment
IATF 16949:2016 & ISO 9001:2015Certified quality system, with APQP, PPAP, FMEA and SPC documentation on every programme.
