For the engineers and designers at Marcus Manufacturing, precision isn’t just a goal—it’s a requirement. This quick reference guide serves as your essential toolkit for specifying die-cast components, ensuring every design is optimized for high-yield, high-quality production.
1. Wall Thickness Guidelines
Maintaining uniform wall thickness is the single most effective way to prevent porosity and warping.
| Alloy | Minimum | Typical | Minimum |
|---|---|---|---|
| Aluminum | 1.5–2.0mm | 2.5–4.0mm | 5.0mm |
| Zinc | 0.8–1.2mm | 1.5–3.0mm | 4.0mm |
| Magnesium | 1.5–2.0mm | 2.5–4.0mm | 6.0mm |
Critical Rule: If thick sections are unavoidable, core them out and use ribs for reinforcement to
2. Mandatory Draft Angles
Draft is not optional; it is the key to preventing drag marks and premature die wear.
- External Surfaces: 1–2° minimum.
- Internal Surfaces: 2–3° minimum (metal shrinks onto these cores).
- Deep Pockets: 3–5° minimum.
- Textured Surfaces: Add 1–2° per 0.025mm of texture depth.
3. General Linear Tolerances (Aluminum)
Zinc alloys typically allow for 20–30% tighter tolerances than the values below.
| Dimension | Tolerance |
|---|---|
| Up to 25mm | ±0.10mm |
| 25–50mm | ±0.15mm |
| 50–100mm | ±0.20mm |
| 100–200mm | ±0.30mm |
| Over 200mm | ±0.30mm + 0.02mm per add'l 25mm |
4. Castable Hole Specifications
Casting holes directly reduces post-machining costs and improves production efficiency.
- Min Diameter (Al): 1.5–2.0mm.
- Min Diameter (Zn): 1.0–1.5mm.
- Depth-to-Diameter Ratio: 4:1 to 6:1 (Economical range).
- Best Practice: Add 1–3° draft to all holes. For holes smaller or deeper than specs, cast a pilot mark and finish via drilling.
5. Fillets, Radii, and Ribs
Avoid sharp corners at all costs. They act as “stress risers” and disrupt metal flow.
- Interior Fillets: 0.5mm minimum (1.0mm preferred).
- Exterior Radii: 0.3mm minimum.
- Rib Design: Rib thickness should be 50–80% of the nominal wall thickness. Use odd numbers (3, 5) to prevent opposing stress points.
6. Tool Life & Production Volume
| Material | Expected Tool Life (Shots) | Economical Batch Size |
|---|---|---|
| Aluminum | 50,000–100,000+ | 2,000+ parts |
| Zinc | 500,000–1,000,000+ | 1,000+ parts |
| Magnesium | 100,000–300,000+ | 2,000+ parts |
7. Material Selection Quick Guide
- A380 (Aluminum): The workhorse. Best balance of fluidity, strength, and corrosion resistance.
- A383 (Aluminum): Best for high-pressure applications requiring leak-tight integrity.
- Zamak 3/5 (Zinc): For ultra-thin walls, high precision, and premium plated finishes.
- Magnesium: For aerospace and electronics where weight reduction is the primary driver.
8. Troubleshooting Checklist
| Defect | Primary Cause | Quick Fix |
|---|---|---|
| Gas Porosity | Air/Hydrogen entrapment | Improve venting or use vacuum assist. |
| Shrinkage | Uneven cooling | Maintain uniform walls; optimize cooling. |
| Cold Shut | Low metal temperature | Increase metal temp and injection speed. |
| Flash | Worn die / Low clamping | Clean die faces; increase clamp tonnage. |
The Marcus Manufacturing Edge
While these specs serve as a baseline, every project at Marcus Manufacturing benefits from a custom DFM review.
When Should You Consult Our Engineering Team?
- When part weight exceeds 2kg.
- If wall thickness variations exceed 50%.
- When tolerances tighter than ±0.15mm are required.
- For complex designs requiring multiple slides or undercuts.
